310 Entry-level Combustion Analyzer

1,313.29 USD 1,313.29 USD 1313.29 USD

4,594.00 AED

310 Entry-level Combustion Analyzer

Entry-level Combustion analyzer, Model no. VAC- 310
Temperature measuring range: -20 to +100 °C
Accuracy: ±1 °C
Resolution: 0.1°C
Battery: 1500 mAh, mains unit 5V/1A
Battery life: 10hrs

VSKU: 1014000046

1,313.29 USD 1,313.29 USD 1313.29 USD

4,594.00 AED

This combination does not exist.

Add to Cart Buy Now

Category:

Gas Detector

Description
Ratings and Reviews

Combustion analyzer to measure gas leak & gas flow velocity

The entry-level combustion analyser is built with a high-quality sensor to measure flue gas, draught, pressure, ambient CO and differential temperature. The sensor has a life of about 6 years. The data stored by the device is transferred to the turbo printer through an infrared interface. The battery has a duration of 10hours. The device is designed to resist impact and damage. The device weighs approximately 700g.

Applications

The combustion analyser can optimise the combustion process to save fuel and costs.
The device facilitates easy measurement of flue gas, draught, pressure, ambient CO and differential temperature.
It is used for draught measurement in the flue gas duct.
It measures burner pressure(nozzle pressure, gas flow pressure etc.).
It facilitates differential temperature measurement (flow and return temperature on heating systems).
The ambient CO concentration can be measured in the heated environment
It measures flue draught on heating systems.
It measures flue gas parameters of burner.

Features

The combustion uses intuitive measurement menus.
The device has a fast response time.
The high-quality sensor technology promises up to a period of 6 years.
An Integrated measurement function enables the measuring of flue gas, draft, CO ambient air and pressure.
It has an easy-to-use guide menu.
The device is provided with a large backlit digital display.
The built-in magnet can stick the device to almost any metal surface.
A direct data transfer function transfers measured values to the turbo printer via an infrared interface.
The device has a rugged design to protects it from impact and damage.
It has an easy to empty condensate collection tank.
The robust design facilitates daily use.
The battery can serve up to a duration of 10hrs.
It has an illuminated LCD display.
The device is powered by a lithium rechargeable battery.

Specifications

It has a dimension of 201 x 83 x 44.
The device operates at a temperature varying from -5 to 45 °C.
The storage temperature varies from -20 to +50 °C.
It can weight 700g approximately.
It is provided with 1500 mAh and mains unit 5V/1A battery.
The battery life duration of the device is10hr.
The TC Type K (NiCr-Ni) ambient temperature has a measuring range -20 to +100 °C, ±1 °C accuracy, 1°C resolution and reaction time < 50 s.
The TC Type J (Fe-CuNi) flue gas temperature has a measuring range of 0 to +400 °C, ±1 °C (0 to +100 °C); ±1.5 % of mv (> 100 °C) accuracy, 0.1 °C resolution and reaction time < 50 s.
The Flue gas O₂ has a measuring range of 0 to 21 Vol.%, ±0.2 Vol.% accuracy, 0.1 Vol.% resolution and reaction time t₉₀ 30 s.
The Flue gas Draught has a measuring range of -20 to +20 hPa, ±0.03 hPa (-3.00 to +3.00 hPa); ±1.5 % of mv (Remaining Range) accuracy and 0.01 hPa resolution.
Flue gas degree of effectivity, The calculated Eta degree of effectivity of flue gas ranges from 0 to 120 %, and has 0.1 % resolution.
The calculated flue gas loss has a measuring range of 0 to 99.9 % and 0.1% resolution.
The Flue gas CO₂ calculation (calculated from O₂) has a measuring range from 0 to CO₂ maximum (Display range), ±0.2 Vol.% accuracy, 0.1 Vol.% resolution and reaction time t₉₀< 40 s.
The pressure has a measuring range of -40 to +40 hPa, ±0.5 accuracy and 0.1 hPa resolution.
The Flue gas CO (without H₂-compensation) has a measuring range of 0 to 4000 ppm, ±20 ppm (0 to 400 ppm); ±5 % of mv (401 to 2000 ppm); ±10 % of mv (2001 to 4000 ppm) accuracy, 1ppm resolution and 60 s reaction time.
The ambient CO has a measuring range of 0 to 4000 ppm, ±20 ppm (0 to 400 ppm); ±5 % of mv (401 to 2000 ppm); ±10 % of mv (2001 to 4000 ppm) accuracy, 1ppm resolution and 60 s reaction time.

We supply these Entry-level combustion analyzers for measuring flue gas, draught, pressure, ambient CO and differential temperature in the USA, UK, Germany, France, Netherlands, Spain, Switzerland, Sweden, and other European countries. Also, we supply these Entry-level combustion analyzers for measuring flue gas, draught, pressure, ambient CO and differential temperature in the USA, UK, Germany, France, Netherlands, Spain, Switzerland, Sweden, and other European countries in the Middle East and other Asian countries including India, Pakistan, Afghanistan, Bangladesh, Singapore, etc.

Our African offices supply these Entry-level combustion analyzers for measuring flue gas, draught, pressure, ambient CO and differential temperature in the USA, UK, Germany, France, Netherlands, Spain, Switzerland, Sweden, and other European countries across all African countries covering South Africa, Kenya, Nigeria, Tanzania, Rwanda, Djibouti, Morocco, Ghana, Ethiopia, Uganda, Morocco, Tunisia, Cameroon, Mauritius, Gabon, Seychelles, etc.

Our Middle East offices supply these Entry-level combustion analyzers for measuring flue gas, draught, pressure, ambient CO and differential temperature. In the USA, UK, Germany, France, Netherlands, Spain, Switzerland, Sweden, and other European countries in the United Arab Emirates, Kingdom of Saudi Arabia, Qatar, Oman, Kuwait, Egypt, Lebanon, Bahrain, Libya, Iraq, Erbil, Jordan, etc.
